Supco L160 L series 240V SPST 60T11 style snap-action temperature control 160°F open/140°F close 60T11-610088

Product Description

The SUPCO L160 is a 240V SPST 60T11 style snap-action temperature control designed for HVACR systems, including furnace air streams, clothes dryers, and heat pump applications. This bimetal disc thermostat features an open on rise action with a fixed 160°F cut-out and a 140°F cut-in, maintaining a precise 20°F differential. Its welded construction ensures integrity of current-carrying components, handling loads up to 25A at 240VAC. It is UL and CSA approved, providing reliable high-limit protection with automatic reset.

• Open on rise switch action ensures circuit breaks upon reaching high-temperature threshold.
• Features 1/4-inch quick disconnect terminals for simplified installation.
• Welded construction maintains integrity of current-carrying components under high-amp loads.

Product Highlights

Critical safety component for HVACR systems, providing high-limit protection with automatic reset.

Product Information

Standard Information

• Brand: SUPCO
• Manufacturer Part Number: L160
• Country of Origin: China

Technical Specifications

• Brand: SUPCO
• MPN: L160
• Input Voltage: 240V
• Switch Type: SPST
• Style: 60T11 Style 610088
• Open Temperature: 160°F
• Close Temperature: 140°F
• Electrical Rating: 60T
• Product Type: HVAC Control Thermostat
• FLA at 120VAC: 10A
• FLA at 240VAC: 5A
• LRA at 120VAC: 60A
• LRA at 240VAC: 30A
• Pilot Duty: 125 VA at 120/240VAC
• RLA at 120/240VAC: 25A
• Certifications: UL, CSA
• Applications: Fan and limit, Domestic Dryer
• Thermostat Type: Bimetal Snap Disc
• Series: L Series
• Disc Size: 3/4 inch (19mm)
• Temperature Differential: 20°F
• Switch Action: Open on Rise
• Reset Type: Automatic
• Resistive Electrical Rating: 25A at 120/240VAC
• Terminals: 1/4-inch Quick Disconnect
• Construction: Welded
• Replacement MPN: 60T11-610088
