Supco a50 Dual Brand Multi-plus V-belt 52 in

Product Description

The SUPCO a50 is a dual-brand Multi-Plus V-belt designed for fractional horsepower (FHP) drive applications in HVAC and light-duty power transmission systems. It carries both the RMA classic part number and the dimensionally equivalent FHP designation on the belt itself, allowing technicians to cross-reference and replace without consulting a separate chart. The belt features a 40-degree angle profile, a top width of 0.50 inches, a height of 0.31 inches, and an approximate outside length of 52 inches. HVAC service techs and equipment mechanics install this belt as a direct replacement in belt-drive blower and fan assemblies.

This belt is suited for residential and light commercial HVAC equipment where belt-drive blower motors are common, including air handlers, furnaces with belt-drive fans, and other FHP motor applications. The dual-brand identification printed on the belt simplifies stocking and field replacement by consolidating two common belt numbering systems into a single part, reducing the number of SKUs a service truck needs to carry.

Key Features

• Dual-brand labeling displays both RMA classic and FHP equivalent part numbers directly on the belt
• 40-degree V-angle profile for standard V-belt drive applications
• Top width of 0.50 inches and height of 0.31 inches
• Approximate outside length of 52 inches
• Designed to reduce V-belt inventory investment by consolidating cross-reference numbers

Compatibility

Designed as an OEM-style replacement V-belt for belt-drive blower and fan assemblies in residential and light commercial HVAC equipment using standard FHP V-belt drives.

Installation Notes

Installation is typically performed by a qualified HVAC technician or equipment mechanic. Always disconnect and lock out power to the unit before removing the belt guard or accessing the drive assembly. Verify pulley alignment and sheave condition before installing the new belt, and confirm the replacement belt length and cross-section match the drive specification. Do not force the belt over pulleys using tools that can damage the cord structure — seat it by hand and adjust belt tension per the equipment manufacturer's deflection specification.

Technical Specifications

• Belt Angle: 40 degrees
• Top Width: 0.50 inches
• Height: 0.31 inches
• Approximate Outside Length: 52 inches

Standard Information

• Brand: SUPCO
• Manufacturer Part Number: a50
