SEALED UNIT PARTS CO HL190 MAGNUS Series 190 Pump

Product Description

The SEALED UNIT PARTS CO HL190 MAGNUS Series 190 pump is designed for effective operation at standard motor speeds. It has heavy-duty, grease-lubricated ball bearings that manage high thrust and radial loads, which helps in maintaining proper shaft alignment. This pump features a Buna mechanical seal along with 'O' ring gasketing for efficient sealing. A self-lubricating carbon idler bushing is included, enhancing its operational longevity. Additionally, the pump comes with an integral relief valve, making it versatile for various applications. The port size is 1.5 NPT, and it achieves a nominal pump rating of 15 GPM or 57 LPM at a pressure of 3.45 BAR (50 PSI) and 20 GPM or 76 LPM at a pressure of 6.9 BAR (100 PSI).

• Designed for nominal motor speeds
• Features oversized ball bearings for high thrust and radial load
• Includes an integral relief valve

Product Highlights

This pump is reliable for HVAC applications and suitable for hydronics systems.

Product Information

Standard Information

• Model No.: GG-190, HJ-190, HL-190, AS-190, AK-190
• Port Size: 1 NPT, 1.5 NPT, 2.5 NPT

Technical Specifications

• Nominal Pump Rating at 3.45 BAR (50 PSI): 15 GPM, 57 LPM
• Nominal Pump Rating at 6.9 BAR (100 PSI): 20 GPM, 76 LPM
• RPM: 950, 1150, 1450, 1750
• Motor Power Required at 3.45 BAR (50 PSI): 0.5 HP to 2 HP
• Motor Power Required at 6.9 BAR (100 PSI): 0.75 HP to 5 HP
• Maximum Hydro-Static Pressure: 400 PSI
• Maximum Recommended Temperature: 225 °F, 107 °C
• Approx. Shipping Weight: 16 LB to 75 LB
