Rcd hy10kb300 Fuse 30A 600V Hvac Circuit Protection

Product Description

The RCD hy10kb300 is a 30-amp, 600-volt melamine fuse designed to protect HVAC circuits from overloads and short-circuit faults. It limits fault current before damage reaches downstream components such as contactors, control boards, and compressors. The melamine body provides thermal stability and arc suppression during a fault event. Licensed HVAC technicians install this fuse as part of routine service or component replacement. At 1 inch in each dimension, it fits standard fuse holders and disconnect blocks commonly found in commercial and residential HVAC equipment.

This fuse is used in HVAC systems where circuit protection components must meet specific voltage and amperage ratings. It is suited for installations requiring a 30A, 600V fuse in line with manufacturer specifications. Compatible equipment identified in product data includes models 30GXR135 850, C50A3 050 53, and 48HCFG17 6 5A. It serves as a genuine OEM-matched replacement in applications where approved component specifications must be maintained.

Key Features

• 30-amp rating with 600-volt capacity for HVAC circuit protection
• Melamine construction supports arc suppression and thermal stability
• Compact 1 inch x 1 inch x 1 inch form factor fits standard fuse holders and disconnect blocks
• Protects downstream components including control boards, contactors, and compressors
• OEM-matched specifications support manufacturer-approved replacement standards

Compatibility

Compatible models identified in product data include 30GXR135 850, C50A3 050 53, and 48HCFG17 6 5A. Designed as an OEM-style replacement fuse for HVAC disconnect and fuse block assemblies requiring a 30A, 600V melamine fuse.

Installation Notes

Fuse replacement should be performed by a licensed HVAC technician. Shut off all power to the unit at the disconnect and verify zero voltage with a meter before handling fuse holders or blocks. Match the replacement fuse amperage and voltage rating exactly to the original — never substitute a higher-rated fuse to bypass a fault condition. Identify and correct the root cause of any fuse failure before restoring power.

Technical Specifications

• Amperage: 30A
• Voltage: 600V
• Length: 1 inch
• Width: 1 inch
• Height: 1 inch
• Material: Melamine

Standard Information

• Brand: RCD
• Manufacturer Part Number: hy10kb300
