Msa Safety 10242707 Swivel D-ring Beam Clamp Anchor

Product Description

The MSA SAFETY 10242707 is a steel puck-style anchor connector designed for fall protection systems in industrial and construction environments. It features a swivel D-ring attachment point mounted on a fixed beam clamp, allowing the connector to orient with load direction during a fall event. The fixed beam clamp configuration installs directly onto structural steel beams without welding or drilling, creating a secure, reusable attachment point rated to 310 pounds. Depth measures 4.375 inches and length measures 3 inches. Licensed HVAC, construction, and rigging professionals working at height install this anchor as part of a compliant personal fall arrest system.

The 10242707 is intended for vertical mounting orientation on structural steel beams in residential, commercial, and industrial job sites. The fixed beam clamp design suits applications where portable anchors are impractical or difficult to manage across a large site. Its compact footprint keeps the connector less obstructive in congested work areas. The reusable design allows the anchor to be repositioned as work progresses along a structure without permanent modification to the beam.

Key Features

• Swivel D-ring attachment point orients with load direction during a fall event
• Fixed beam clamp mounts to structural steel without welding or drilling
• 310 pound weight capacity for fall arrest applications
• Reusable construction allows repositioning as work location changes
• Compact profile reduces obstruction in tight work areas
• Steel construction for durability in demanding job site conditions

Compatibility

Designed for use as a beam clamp anchor connector in vertical-orientation fall protection systems on structural steel beams. Consult applicable ANSI and OSHA fall protection standards to confirm fitment within your specific personal fall arrest system configuration.

Installation Notes

Installation and inspection of fall protection anchors must be performed by a competent person as defined by OSHA 29 CFR 1926.502 and applicable fall protection regulations. Confirm the structural steel beam is rated to support the required anchor load before clamping. Inspect the swivel D-ring and clamp hardware for wear, deformation, or corrosion before each use. Do not install on beams outside the clamp's rated flange range or in orientations other than vertical without consulting the manufacturer documentation.

Technical Specifications

• Attachment Point: Swivel D-Ring
• Beam Clamp Style: Fixed
• Mounting Orientation: Vertical
• Weight Capacity: 310 lb
• Depth: 4.375 inches
• Length: 3 inches
• Overall Width: 3 inches
• Material: Steel
• Anchor Installation: Reusable
• Country of Origin: Taiwan (subject to change)

Standard Information

• Brand: MSA SAFETY
• Manufacturer Part Number: 10242707
