Msa Safety 10242706 Swivel D-ring Anchor Connector

Product Description

The MSA SAFETY 10242706 is a fixed beam clamp anchor connector with a swivel D-ring attachment point, designed for fall protection applications in vertical orientation. Constructed from steel, this anchor clamps to structural steel beams to establish a secure, permanent or semi-permanent tie-off point. With a weight capacity of 310 pounds, it meets the load demands of personal fall arrest systems used in construction, maintenance, and industrial environments. The compact footprint keeps the anchor from obstructing work areas, making it a practical choice where clearance is limited. Licensed fall protection professionals and safety-trained tradespeople are the primary installers of this type of anchor.

This anchor connector is suited for use on structural steel beams where a reusable, fixed mounting solution is required. The fixed beam clamp eliminates the need to weld or drill into the beam, allowing installation and removal without permanent modification to the structure. It is commonly used on large jobsites where permanent or semi-permanent anchor points reduce the risk of misplaced portable solutions. Vertical mounting orientation makes it appropriate for overhead beam installations typical in steel-framed buildings, bridges, and industrial facilities.

Key Features

• Swivel D-ring attachment point allows connected hardware to rotate freely, reducing torque on the connector
• Fixed beam clamp style attaches directly to structural steel beams without welding or drilling
• 310-pound weight capacity meets standard fall arrest load requirements
• Steel construction provides durability in demanding work environments
• Reusable anchor rated for vertical mounting orientation
• Compact dimensions minimize obstruction in tight work areas

Compatibility

Designed as an OEM-style fixed beam clamp anchor for use with standard fall protection lanyards, self-retracting lifelines, and connecting hardware compatible with a swivel D-ring attachment point in vertical orientation.

Installation Notes

Installation should be performed by a qualified person familiar with OSHA fall protection regulations and the applicable requirements of ANSI Z359 standards. Before installing or removing the anchor, ensure all personnel in the area are clear and that no load is applied to the connector. Verify that the structural beam to which the clamp is attached meets the anchorage strength requirements specified by the fall protection system manufacturer. Inspect the anchor connector for visible damage, corrosion, or deformation before each use.

Technical Specifications

• Attachment Point: Swivel D-Ring
• Beam Clamp Style: Fixed
• Mounting Orientation: Vertical
• Weight Capacity: 310 pounds
• Depth: 6.25 inches
• Length: 2.375 inches
• Overall Width: 2.375 inches
• Anchor Material: Steel
• Anchor Installation: Reusable
• Country of Origin: Taiwan (subject to change)

Standard Information

• Brand: MSA SAFETY
• Manufacturer Part Number: 10242706
