Maxitrol RV47CL-3/8 3/8 Inch Gas Regulator with Limiter for Natural and LP Gas Applications

Product Description

The Maxitrol RV47CL-3/8 is a robust 3/8 inch regulator designed for precise control in main burner and pilot load applications. It is ideal for both natural and LP gas setups.

• Equipped with an integral vent limiting orifice for safety.
• Constructed from high strength aluminum, ensuring long-lasting durability.
• Convertible design enabling easy adaptation between natural and LP gases.

Product Highlights

Suitable for varied residential and commercial setups. Tested for multi-poise installation without flow restrictions. Note: Installation by a licensed gas fitter recommended.

Product Information

Standard Information

• Brand: Maxitrol
• MPN: RV47CL-3/8

Technical Specifications

• Size: 3/8 inch
• Max Inlet Pressure: 1/2 PSI
• BTU Capacity: 125000 for burner and pilot, 40000 for fixed orifice
• Material: Aluminum
• Dimensions: 8.01 inches (Length) x 9.01 inches (Width) x 8.01 inches (Height)
