Mars 33232 24 V 1 to 24 Sec On 45 to 75 Sec Off 1-DPST/1-SPST Electric Heat Sequencer

SUPCO
Brand: SUPCO
SKU: 33232
Availability: In Stock

Ships same day if ordered by 12 pm
$44.48
$44.48
Manuals:
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

The Mars Motors & Armatures 33232 is a 24 Volt electric heat sequencer designed for efficient control in various heating applications.

  • Voltage: 24 V
  • Timing range: 1 to 24 seconds on, 45 to 75 seconds off
  • Contact configuration: 1 DPST and 1 SPST

Product Highlights

This device provides reliable timing and control for blower and heating element systems. It is ideal for HVAC professionals needing solid state performance and multiple switch options.

Product Information

Standard Information

  • Manufacturer: Mars Motors & Armatures
  • UPC: 685744332329

Technical Specifications

  • Type: Solid State
  • Voltage Rating: 24 Volt
  • Timing Mode: On/Off Delay
  • Timing Range: 1 to 24 Seconds On, 45 to 75 Seconds Off
  • Contact Configuration: (1) DPST, (1) SPST
  • Number of Switches: 3
  • Ambient Temperature Rating: 20 to 160 Deg F
  • Approval: UL, CSA
