International Comfort Products EVMWX30M17A ICP Horizontal Cased Evaporator V-Coil, Service Use 2.5 Ton 30,000 BTU/hr 17 Inch

Product Description

The INTERNATIONAL COMFORT PRODUCTS EVMWX30M17A is a 2.5 Ton horizontal cased evaporator V-coil designed for HVAC/R systems using R-410A refrigerant. This unit provides 30,000 BTU/hr cooling capacity with a flow rate of 750 to 1250 cfm. It features a durable, 24-gauge, pre-painted cabinet with R-2.1 insulation for efficient operation. The coil includes a factory-installed TXV and a corrosion-resistant PBT drain pan with proper slope for improved moisture removal. Its design allows for easy servicing and cleaning.

• Incorporates proven standards for reliable system operation and performance, with AHRI-rated performance and UL/c-UL listing.
• Features a durable, 24-gauge, pre-painted cabinet with R-2.1 insulation and a corrosion-resistant PBT drain pan with three water-tight drain plugs.
• Designed with lower pressure drops for enhanced system performance and airflow, including factory-installed TXVs and UV knockouts.

Product Highlights

This cased evaporator V-coil offers reliable R-410A cooling, efficient airflow, and simplified maintenance for HVAC/R applications.

Product Information

Standard Information

• Brand: INTERNATIONAL COMFORT PRODUCTS
• Manufacturer Part Number: EVMWX30M17A

Technical Specifications

• Cooling Capacity: 30,000 Btu/hr
• Flow Rate: 750 to 1250 cfm
• Nominal Capacity: 2.5 ton
• Refrigerant Type: R-410A
• Series: EVMWX
• Air Flow Type: Upflow / Downflow
• Color: Cool Gray
• Hairpin Material: Microchannel
• Installation Configuration: Multi Position/ Horizontal
• Liquid Line Size: 3/8 in
• Manufacturer: International Comfort Products
• Manufacturer Part Number: EVMWX30M17A
• Metering Device: TXV
• Suction Line Size: 3/4 in
• Product Type: Evaporator Coils
• Coil Type: Cased Multipoise V-Coil
