Ewc Controls EBMPLUS-7000 BMPLUS 7000 control panel 24V

Product Description

The EWC CONTROLS EBMPLUS-7000 is a 24V control panel designed for upgrading single-zone HVAC systems into multi-zone, energy-saving solutions. This control panel supports 2 heat and 2 cool stages with auto changeover, operating within a 19-30 VAC input voltage range. It functions reliably across an operating temperature range of -20°F to 160°F and a humidity range of 0 to 95% RH (non-condensing), making it suitable for residential and light commercial forced air zoning.

• Supports 2 Heat/2 Cool stages for versatile HVAC control.
• Operates on a 24V system with 19-30 VAC input voltage.
• Features an LED Display and built-in timers for enhanced functionality.

Product Highlights

Upgrade inefficient single-zone HVAC systems to multi-zone with this 24V control panel, offering energy savings and comfort.

Product Information

Standard Information

• Brand: EWC CONTROLS
• Manufacturer Part Number: EBMPLUS-7000

Technical Specifications

• Product Type: Control Panel
• Stages: 2 Heat/2 Cool
• Changeover: Auto
• Voltage: 24V
• Input Voltage: 19-30 VAC (60 Hz)
• Operating Temperature Range: -20°F - 160°F
• Humidity Range: 0 to 95% RH (Non Condensing)
