Abb Installation Products CTL30-12 Compression Lug, 1-Hole, 3/0 AWG, 1/2 Inch Stud

Product Description

The ABB INSTALLATION PRODUCTS CTL30-12 is a Color-Keyed® 1-Hole Compression Lug designed for use with 3/0 AWG flexible or stranded copper conductors and a 1/2 inch stud. It is constructed from high conductivity seamless copper tubing and tin plated for corrosion resistance. The lug can be used for medium voltage applications up to 35 kV with proper insulation techniques.

• Made of high conductivity seamless copper tubing
• Tin plated for corrosion-resistance
• Specially chamfered barrel for ease of installation

Product Highlights

This compression lug features color coding for matching die identification and a specially chamfered barrel for easy installation.

Product Information

Standard Information

• Brand: ABB INSTALLATION PRODUCTS
• Manufacturer Part Number: CTL30-12
• Country of Origin: Mexico

Technical Specifications

• Conductor Size: 3/0 AWG
• Stud Size: 1/2 in
• Type: 1-Hole Compression Lug
• Conductor Type: Flexible/Stranded Copper
• Series: CTL
• Voltage Rating: 35 kV
• Tongue Type: Straight
• Overall Length: 2-11/32 in
• Barrel Type: Short/Standard
• Barrel Size: 13/16 in L
• Material: Copper, Tin-plated
• Stud Holes: 1
• Application: Confined Areas, Industrial and Building Applications
