Abb Installation Products 54171nl Octagon Box 22.5 Cu in

Product Description

The ABB INSTALLATION PRODUCTS 54171nl is a pre-galvanized steel octagon outlet box designed for flush mounting in walls and ceilings in residential and light commercial electrical installations. At 22.5 cubic inches of usable volume, it meets NEC fill requirements for standard wiring configurations. The drawn steel construction provides a rigid, one-piece housing. It ships with non-metallic cable clamps (C-5 style) and an L bracket already installed, making it ready for direct use with non-metallic sheathed cable (NM/Romex-type wiring). Licensed electricians performing rough-in work are the primary installers of this box.

This octagon box is suited for ceiling and wall fixture applications in new construction and retrofit projects where non-metallic sheathed cable is the wiring method. The included L bracket supports mounting to framing members, and the 1/2 inch knockouts accommodate standard conduit connectors or cable entry points. The 4 inch diameter footprint is a common standard size for ceiling-mounted light fixtures and junction points in residential branch-circuit wiring.

Key Features

• 22.5 cubic inch capacity supports NEC fill calculations for typical residential wiring
• Pre-galvanized drawn steel construction for durability and corrosion resistance
• 1/2 inch knockouts for standard cable or connector entry
• Includes non-metallic cable clamps (C-5) for securing NM sheathed cable
• Includes L bracket for attachment to wall or ceiling framing
• UL listed under E2969

Compatibility

Designed for use with non-metallic sheathed cable (NM cable) in residential and light commercial wiring applications. Suitable as an OEM-style outlet box for ceiling fixture and junction box installations where a 4 inch octagon form factor is required.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and applicable local codes. De-energize the circuit at the panel and verify absence of voltage before beginning work. Secure all non-metallic sheathed cables with the provided C-5 clamps before making wire connections. Do not exceed the 22.5 cubic inch fill capacity when calculating conductor and device fill per NEC Article 314.

Technical Specifications

• Cubic Capacity: 22.5 cubic inches
• Diameter: 4 inches
• Depth: 2-1/8 inches
• Knockout Size: 1/2 inch
• Material: Pre-Galvanized Steel
• Construction: Drawn
• Color: Silver
• Number of Outlets: 1
• Included Hardware: Non-Metallic Cable Clamps (C-5), L Bracket
• Listing: UL E2969
• Application: Non-Metallic Sheathed Cable

Standard Information

• Brand: ABB INSTALLATION PRODUCTS
• Manufacturer Part Number: 54171nl
