Abb E950HGR Pvc Conduit Reducer 1.5x1.25 in Male Female

Product Description

The ABB INSTALLATION PRODUCTS E950HGR is a PVC conduit reducer designed to connect two conduit sections of different diameters in a single raceway run. It transitions from a 1.5-inch male spigot end to a 1.25-inch female bell end, maintaining a secure, solvent-weld-ready joint without the need for additional adapters. Weighing 0.53 pounds, this reducer is suited for both exposed and concealed conduit installations where a size reduction is required. Electricians use this fitting to maintain raceway continuity when conduit sizing changes between panels, junction boxes, or inline transitions.

This reducer is appropriate for use in residential, commercial, and light industrial electrical conduit systems. The bell-and-spigot configuration makes it compatible with standard PVC conduit solvent-cement joining methods. It is a common fitting in branch circuit raceways, service entrance runs, and conduit stub-ups where a change in conduit trade size is required at a connection point. Sold in packages of 7 units, making it practical for multi-run installations or service vehicle stocking.

Key Features

• Reduces 1.5-inch conduit to 1.25-inch conduit in a single fitting
• Male spigot x female bell end configuration for solvent-weld joining
• PVC construction resists moisture, corrosion, and common chemical exposure
• Lightweight at 0.53 pounds per unit
• Packaged in quantities of 7 for multi-run or stocking efficiency

Compatibility

Designed as an OEM-style replacement fitting for standard PVC electrical conduit systems requiring a 1.5-inch to 1.25-inch reducer transition with a bell-and-spigot joint.

Installation Notes

Installation is performed by licensed electricians in accordance with NEC Article 352 governing rigid PVC conduit. De-energize any circuits associated with the raceway before opening or modifying conduit runs. Apply a listed PVC conduit solvent cement to both the spigot end and the interior of the bell end before joining, and allow adequate cure time per the cement manufacturer instructions before pulling wire. Avoid over-reaming the bell end, as this can compromise joint integrity.

Technical Specifications

• Material: PVC
• Inlet Size: 1.5 inches (Male Spigot)
• Outlet Size: 1.25 inches (Female Bell)
• End Configuration: Bell x Spigot
• Weight: 0.53 pounds
• Package Quantity: 7 units per package

Standard Information

• Brand: ABB INSTALLATION PRODUCTS
• Manufacturer Part Number: E950HGR
