Zurn z6956-sd Sensor Soap Dispenser 1600ml Chrome

Product Description

The ZURN z6956-sd is a deck-mount, sensor-activated liquid soap dispenser designed for hands-free operation in commercial and residential restroom applications. Built with chrome-plated cast brass, it features a seamless body with smooth curves suited to a refined sink deck installation. The unit holds a 1600ml (54.1 oz) refillable soap bottle and dispenses up to 2 ml per cycle across four adjustable output settings. Compatible soap viscosity ranges from 100 to 3500 cPs. Power options include a battery pack with four D-cell batteries, an A/C adapter, or A/C power with battery backup — all power sources are included. Licensed plumbers and commercial fixture installers handle this type of installation.

The z6956-sd is part of the Cumberland product line and is designed to complement the ZURN Z6956-XL Cumberland faucet for a coordinated, fully automatic hand-washing station. It is suited for deck-mount installations in restrooms where hands-free dispensing is required to reduce cross-contamination. The unit mounts through a deck hole ranging from 1 inch to 1-1/4 inches in diameter. Installation requires 18 inches of vertical clearance and 12 inches of horizontal space below the counter to accommodate the reservoir and battery box.

Key Features

• Sensor-activated, hands-free dispensing reduces germ transfer at shared sinks
• Three power configurations: battery pack, A/C adapter, or A/C with battery backup
• 1600ml (54.1 oz) refillable soap bottle supports high-traffic use between refills
• Adjustable dispense volume up to 2 ml per cycle across four settings
• Rated for 100,000 cycle battery life using four D-cell batteries
• Chrome-plated cast brass construction for durability and finish consistency

Compatibility

Designed to complement the ZURN Z6956-XL Cumberland faucet for a matched automatic hand-washing system. Accepts soaps with a viscosity between 100 and 3500 cPs. Mounts through deck holes from 1 inch to 1-1/4 inches in diameter.

Installation Notes

Installation is typically performed by a licensed plumber or commercial fixture technician. Shut off power at the source before connecting the A/C adapter. Confirm 18 inches of vertical clearance and 12 inches of horizontal space beneath the counter before mounting to accommodate the soap reservoir and battery compartment. Follow local plumbing codes for deck-mount accessory installations.

Technical Specifications

• Capacity: 1600ml (54.1 oz) refillable soap bottle
• Dispense Volume: Up to 2 ml per cycle, 4-setting adjustable
• Soap Viscosity Range: 100 to 3500 cPs
• Battery Life: 100,000 cycles (4 D-cell batteries)
• Power Options: Battery pack, A/C adapter, or A/C with battery backup
• Mounting Hole Diameter: 1 inch to 1-1/4 inches
• Required Undercounter Clearance: 18 inches vertical, 12 inches horizontal
• Construction: Chrome-plated cast brass
• Operation: Automatic sensor-activated
• Finish: Polished chrome

Standard Information

• Brand: ZURN
• Manufacturer Part Number: z6956-sd
