ZURN Z1201-NR4-JC Zurn Z1201-NR4-JC EZCarry High Performance Water Closet Carrier

Product Description

The Zurn Z1201-NR4-JC EZCarry water closet carrier is designed for efficient installation and reliable performance. This water closet carrier system features a horizontal siphon jet design. It includes a right-hand inlet with flow directed to the left, ensuring effective waste removal. The main fitting is constructed from Dura-Coated cast iron and has a four-inch no-hub connection along with an extended two-inch vent for optimal flow performance.

• Supports loads up to 500 lbs for heavy-duty use.
• Meets ASME A112.6.1M standards for safety and reliability.
• Features adjustable components for customized installation.

Product Highlights

This closet carrier includes a gasketed faceplate and a heavy-duty rear anchor tie-down. Its adjustable coupling has an integral test cap to simplify inspection and maintenance. The pre-fabricated, slotted foot supports are designed for top anchoring, providing stability during and after installation.

Product Information

Standard Information

• Product Type: Closet Carrier
• Collection: EZCarry

Technical Specifications

• Material: Cast Iron
• Fitting Size: Four inches
• Static Load Rating: 500 lbs
• Installation Type: Floor Mount
• Dimensions: 20-3/4 inches Depth, 17-7/8 inches Height, 20-3/4 inches Length, 17-1/8 inches Width
• Main Fitting: Dura-Coated cast iron with a four-inch no-hub connection
• Flow Design: Horizontal siphon jet system
• Sealing: Includes a bonded Neo-Seal gasket
