Zurn 34-P1500XL Model P1500XL 3/4 in. Pressure Relief Valve

Product Description

The Zurn pressure relief valve with MPN 34-P1500XL is designed to protect cold water service lines from excessive pressure buildup. This model is ideal for a variety of applications including static relief, low capacity pump relief, passive solar systems, and thermal expansion relief in commercial and industrial settings.

• Male NPT inlet and female NPT outlet for easy installation
• Field adjustable settings from twenty-five to one hundred seventy-five psi
• Lead-free construction for safe use in potable water applications

Product Highlights

This pressure relief valve is built to meet stringent standards and offers durability with its cast bronze body and stainless steel components. The adjustable PSI settings allow for customized pressure regulation to fit specific demands.

Product Information

Standard Information

• Brand: Zurn Wilkins
• Model Number: 34-P1500XL

Technical Specifications

• Application: Commercial
• Material: Low Lead Cast Bronze
• Maximum Working Water Pressure: 175 psi
• Maximum Working Water Temperature: 210 degrees F
• Connection Size: 3/4 x 3/4 inches
• Connection Type: MNPT x FNPT
• Width: 1.2 inches
• Height: 1.2 inches
• Length: 2.1 inches
• Weight: 0.5 lbs
