Zurn 1260XL-E Water Hammer Arrestor (1 in) Replaces 1250XL-E

Product Description

The ZURN 1260XL-E Water Hammer Arrestor protects water lines against over-pressure during surges following quick valve closure. It is suitable for residential, commercial, and industrial applications. Excessive pressure surges are absorbed by the pre-charged air cushion that is permanently sealed within the water hammer arrestor. It can be installed within a stud bay, eliminating the need for an access panel.

• Reduces pipe banging caused by water hammer
• Eliminates need for access panel through installation within stud bay
• Air chamber is permanently sealed to eliminate excessive pressure surges

Product Highlights

The Zurn 1260XL-E water hammer arrestor features copper and brass external construction and is low-lead law compliant.

Product Information

Standard Information

• Brand: ZURN
• Manufacturer Part Number: 1260XL-E

Technical Specifications

• Length: 1 in / 2.54 cm
• Width: 1 in / 2.54 cm
• Height: 1 in / 2.54 cm
• Temperature range: -40 0 F to 212 0 F
• End connections: Threaded ANSI/ASME B1.20.1
• Maximum transient pressure surge: with arrester properly sized and placed in the water supply system, will not rise above 150 psi following quick valve closure.
• Maximum static pressure: 200 psi.
• Max spike pressure: 400 psi
• Brand: Zurn Wilkins
• Body Material: Copper Tube
• End Style: MNPT
• Fixture Unit Capacity: 114 to 154
• Nominal Size: 1 in
• Series: 1260XL
• Softgoods Material: EPDM O-Ring
• Temperature Rating: -40 to 212 deg F
• Manufacturer Part Number: 1260XL-E
• Thread: 1" MNPT
