Zoro G2402951 Mini Ball Valve 3/8 inches MNPT x Push

Product Description

The ZORO G2402951 mini ball valve is manually operated with a nickel-chrome plated brass body, designed for air, oil, and water media. This valve features a one-piece construction with a straight valve body style and a full port ball. It has a maximum operating pressure of 190 psi and a temperature range of 0 to 200 degrees F.

• 1/4 Turn Shut-Off
• Blowout Resistant Stem
• Connection Type: MNPT x Push

Product Highlights

The ZORO mini ball valve is ideal for use with air, oil, and water. It offers a 1/4 turn shut-off and a blowout resistant stem.

Product Information

Standard Information

• Brand: ZORO
• Manufacturer Part Number: G2402951
• Country of Origin: United States

Technical Specifications

• MFR #: 86330-06-06
• Zoro #: G2402951
• Country of Origin: United States
• Pipe Size: 3/8 in
• Overall Length: 1.77 in
• Thread Size: 3/8 in
• Connection Size - Side 2: 3/8 in
• Connection Size - Side 1: 3/8 in
• Handle Height: 0.85 in
• Handle Length: 0.75 in
• Nominal Valve Size: 3/8 in
• Ball Material: Chrome Plated Brass
• Body Style: Inline
• Ball Port Style: Full Port
• Valve Ways: 2-Way
• Valve Structure: One-Piece
• For Media: Air, Oil, Water
• Connection Type: MNPT x Push
• Item: Mini Ball Valve
• Body Material: Brass
• Features: 1/4 Turn Shut-Off
• Handle Type: Wedge
• Temp. Range: 0 Degrees to 200 Degrees F
• Handle Material: Composite
• Stem Type: Blowout Resistant
• Standards: CE Listed, REACH
• Max. Pressure: 190 PSI CWP
• Ball Valve Product Group: Manual
• Stem Material: Nickel-Plated Brass
• Seat Material: PTFE
• Seal Material: Buna-N
• Connection Type - Side 1: NPT
• Connection Gender - Side 1: Male
• Connection Gender - Side 2: Male
• 3-A Standard Compliance: Not Rated
• Maximum Pressure - Combustible Gas: Not Rated
• Operating Temperature - Maximum: 200 Degrees F
• Operating Temperature - Minimum: 0 Degrees F
