ZoomLock 870511 1-3/8 Copper Press-to-Connect Coupling

Product Description

The ZoomLock 870511 is a press-to-connect coupling designed for connecting sections of copper pipe in HVAC and refrigeration systems. This copper fitting allows for a secure, leak-free connection without the need for brazing. It is compatible with ZoomLock MAX systems and fits pipes with an outer diameter of one and three-eighths inches. The coupling works with various refrigerants, including 32, 125, 134a, 290, 404A, and 410A.

• Connects two sections of copper piping.
• Ensures a secure and leak-free joint.
• Compatible with ZoomLock MAX systems.

Product Highlights

This coupling provides ease of installation and reliable performance for HVAC and refrigeration applications.

Product Information

Standard Information

• Brand: ZoomLock
• Material: Copper

Technical Specifications

• MPN: 870511
• Fitting Type: Coupling
• Connection Type: Press-to-Connect
• Connection Size 1: 1-3/8 inches
• Connection Size 2: 1-3/8 inches
• Refrigerants Compatible: 32, 125, 134a, 290, 404A, 410A
• Pressure Rating: 700 psi
• Temperature Rating: -40 to 250 degrees Fahrenheit
• Series: ZoomLock MAX
• Additional Information: HNBR O-Ring, 2100 psi Minimum Burst Pressure
