Zoeller ZOEL-53-0003 Effluent Pump 0.3 Hp 230V Automatic

Product Description

The ZOELLER ZOEL-53-0003 is a submersible effluent and dewatering pump rated at 0.3 HP, 230 volts, single phase, drawing 4.8 amps. Built on the Model D53 Mighty-Mate platform, it delivers up to 43 GPM flow at a maximum head of 19.25 feet. The discharge is a 1-1/2 inch NPT connection. A 9-foot power cord and automatic float switch are included, making this a ready-to-install unit. The pump body is cast iron with a powder-coated epoxy finish that resists corrosion and aids motor heat dissipation. Licensed plumbers and pump service technicians typically install this unit in residential or light commercial wet-pit applications.

This pump is suited for residential and light commercial dewatering, groundwater transfer, and effluent handling. Typical installations include septic system effluent sumps, crawl space dewatering pits, and construction site water removal. The automatic float switch activates and deactivates the pump based on water level, reducing the need for manual monitoring. Each unit is pressure-tested, submerged, and run at the factory before shipment, confirming hydraulic and electrical integrity prior to field installation.

Key Features

• 0.3 HP motor rated at 230 volts, single phase, 4.8 amps
• Maximum flow rate of 43 GPM with a maximum head of 19.25 feet
• 1-1/2 inch NPT discharge connection for standard plumbing integration
• Cast iron construction with powder-coated epoxy finish for corrosion resistance and heat dissipation
• 9-foot power cord included for flexible sump placement
• Automatic float switch operation eliminates need for manual intervention
• 100% factory pressure-tested, submerged, and run before leaving the facility

Compatibility

Designed as an OEM-style replacement or direct installation option for residential and light commercial effluent and dewatering sump applications requiring a 1-1/2 inch NPT discharge submersible pump.

Installation Notes

Installation should be performed by a licensed plumber in accordance with applicable local plumbing codes and the International Plumbing Code (IPC). Disconnect and lock out all electrical power before servicing or repositioning the pump. Confirm the sump basin diameter and discharge line sizing are compatible with the 1-1/2 inch NPT outlet before installation. Do not run the pump dry, as the motor relies on submersion for cooling.

Technical Specifications

• Horsepower: 0.3 HP
• Voltage: 230 volts
• Phase: 1 Phase
• Amperage: 4.8 amps
• Discharge Size: 1-1/2 inches NPT
• Maximum Flow Rate: 43 GPM
• Maximum Head: 19.25 feet
• Cord Length: 9 feet
• Operation: Automatic
• Motor Housing Material: Cast Iron
• Finish: Powder-Coated Epoxy

Standard Information

• Brand: ZOELLER
• Manufacturer Part Number: ZOEL-53-0003
