Zoeller BN161 High Head Effluent Pump 0.5 HP (1-1/2 inches NPT) 161-0026

Product Description

The Zoeller BN161 is a submersible high-head effluent and dewatering pump rated 0.5 HP and 115 V, designed for residential and light commercial septic, effluent lift, and low-pressure piping applications. The pump uses a bronze non-clogging vortex impeller and an oil-filled, hermetically sealed motor with automatic-reset thermal overload protection. It provides up to 100 GPM and a maximum head of 57 ft, passes 3/4" spherical solids, and has a 1-1/2" NPT discharge with a 20 ft power cord and variable level float switch.

• Durable cast iron housing with powder-coated epoxy finish; bronze vortex impeller passes 3/4" (19 mm) solids
• Oil-filled, hermetically sealed PSC motor, 3450 RPM, automatic-reset thermal overload protection
• 1-1/2" NPT discharge, up to 100 GPM flow, maximum head 57 ft; 20 ft cord and variable-level float switch

Product Highlights

0.5 HP, 115 V, 1 phase; bronze vortex impeller; oil-filled sealed motor; 1-1/2" NPT discharge; passes 3/4" solids; rated to 130�F; 20 ft cord and variable float switch.

Product Information

Standard Information

• Brand: ZOELLER
• Manufacturer Part Number: BN161
• Country of Origin: United States
