Product Description
The ZOELLER 30-0152 is a 2" FPT Cast Iron Check Valve. Designed for residential and commercial pumps, this valve provides a reliable solution for managing wastewater and effluent. It features a cast iron construction and a threaded connection type for secure installation. Suitable for vertical or horizontal mounting positions.
- 2" Size
- Cast Iron Material
- Threaded Connection Type
- Full-Flow Design
Product Highlights
This cast iron check valve is ideal for sewage and effluent pump applications, offering full-flow performance and easy installation.
Product Information
Standard Information
-
Brand: ZOELLER
-
Manufacturer Part Number: 30-0152
-
Country of Origin: United States
Technical Specifications
-
Material: Cast Iron
-
Inlet Connection Type: National Pipe Tapered
-
Manufacturer: Zoeller
-
Model / MPN: 30-0152
-
Size: 2"
-
Connection Type: Threaded
-
Category: Check Valve
-
Flow: Full Flow
-
Width: 6 5/8 in
-
Length: 6 5/8 in
-
Pipe Size: 2 in
-
Connection: FNPT
-
Body Material: Cast iron
-
Max. Pressure: 50 psi @ 130 Degrees F
-
Seal Material: Neoprene
-
Seat Material: Cast Iron
-
Overall Height: 8 in
-
Mounting Position: Vertical or Horizontal
-
Max. Temp. - Valves: 130 Degrees F
-
Valve Body Material: Cast Iron
-
Application - Valves: Pumps
-
Mounting Orientation: Horizontal, Vertical
-
End Connection: Female NPT
-
Pressure: 50PSI
-
Temperature: 130DEG F
-
Part Number: 30-0152
-
Application: Pump
-
Height: 8IN
-
Type: Unicheck Valve
-
Water Connection: 2"
-
Water Connection Type: NPT
-
Check Mechanism: Swing
-
Valve Body Style: Inline
-
For Media: Water
-
Connection Type - Side 1: NPT
-
Connection Gender - Side 1: Female
-
Connection Size - Side 2: 2 in
-
Connection Type - Side 2: NPT
-
Connection Gender - Side 2: Female
-
Max. Pressure (CWP): 50 psi
-
Max. Pressure (Steam): Not Rated
-
Cracking Pressure: 1 psi
-
Media Temp. Range: 75 °F to 130 °F
-
Operating Temperature - Minimum: 75 °F
-
Operating Temperature - Maximum: 130 °F
-
Disc Material: Cast Iron
-
Overall Length: 6 in
-
Manufacturer Warranty: 1 yr
-
UNSPSC: 40141622
-
Inlet Port: 2 in
-
Pressure Rating: 50 psi
-
Temperature Rating: 130 deg F
