Zodiac Pool System fled-c-tr-150-pk4 Led Underwater Light

Product Description

The ZODIAC POOL SYSTEM fled-c-tr-150-pk4 is a 12 VAC, 5-watt RGB LED underwater light designed for in-ground pool installations. Part of the Treo product line, it features a replaceable LED lamp rated for 50,000 hours of service life and ships with a 150-foot low-voltage cord for deep niche or remote equipment pad runs. The fixture measures 3.5 inches in diameter by 13/16 inches in depth, making it a low-profile fit for standard pool light niches. Pool service technicians and licensed electricians install this light in new construction and retrofit applications across gunite, vinyl liner, and fiberglass pool types.

This fixture is suited for residential and light commercial pool lighting installations where full-color RGB output and long cord length are required. The 150-foot cord accommodates pools where the equipment pad is set well back from the water. Four trim rings are included in the package: white, black, beige, and gray, allowing the installer to match the coping or deck finish without sourcing additional parts. The replaceable lamp module reduces long-term service cost compared to sealed fixture designs.

Key Features

• 12 VAC, 5-watt RGB LED output for full-color underwater illumination
• Rated 50,000-hour average lamp life with a field-replaceable LED module
• 150-foot low-voltage cord included for long equipment pad runs
• Compatible with gunite, vinyl liner, and fiberglass pool construction types
• Ships with four trim rings: white, black, beige, and gray
• ETL Listed; conforms to UL 676; certified to CSA C22.2 No. 89

Compatibility

Designed for gunite, vinyl liner, and fiberglass pools requiring a 12 VAC low-voltage underwater light fixture with an RGB LED lamp.

Installation Notes

Installation must be performed by a licensed electrician or qualified pool service professional in accordance with the National Electrical Code (NEC) Article 680 and all applicable local codes. Shut off and lock out the pool light circuit at the breaker before handling the fixture or cord. The low-voltage transformer must be rated for the total connected load and mounted at the required height above water level per NEC guidelines. Do not energize the fixture outside of water.

Technical Specifications

• Voltage Rating: 12 VAC
• Power Rating: 5 watts
• Light Color: RGB
• Average Lamp Life: 50,000 hours
• Cable Length: 150 feet
• Fixture Diameter: 3.5 inches
• Fixture Depth: 13/16 inches
• Shipping Dimensions: 12 inches x 12 inches x 5.5 inches
• Included Accessories: Low-voltage cord, trim rings in white, black, beige, and gray
• Certifications: ETL Listed, conforms to UL 676, certified to CSA C22.2 No. 89
• Application: Gunite, vinyl liner, and fiberglass pools

Standard Information

• Brand: ZODIAC POOL SYSTEM
• Manufacturer Part Number: fled-c-tr-150-pk4
