Zebra zslck Splicing Wire Connector 250V 32A

Product Description

The ZEBRA zslck is a compact splicing wire connector designed for fast, reliable electrical splicing in residential and light commercial wiring applications. Rated at 250 volts and 32 amps, it accepts solid wire from 28 to 12 AWG and stranded wire from 28 to 14 AWG, covering a broad range of conductor sizes used in control wiring, fixture work, and general branch-circuit connections. The connector body is molded from flame-retardant nylon PA66 material for durability and code-appropriate fire resistance. A built-in test point allows technicians to probe the connection with a meter without disturbing the splice, saving time during troubleshooting and inspection.

This connector is suited for use in junction boxes, panel wiring, fixture installations, and low-voltage control circuit splicing. The required strip length is 0.375 inches, keeping prep time consistent across installations. Electricians, HVAC technicians, and maintenance professionals working on control boards, lighting circuits, and general wiring will find this connector fits standard splicing workflows. It is available in a standard carton of 24 pieces, making it practical for stocking service vehicles and supply rooms.

Key Features

• Built-in test point for meter probing without opening the splice
• Rated 250 volts and 32 amps for broad low-voltage and branch-circuit use
• Accepts 28-12 AWG solid and 28-14 AWG stranded conductors
• Flame-retardant nylon PA66 body for code-appropriate fire resistance
• Compact form factor suitable for tight junction box installations
• Consistent 0.375-inch strip length for repeatable prep

Compatibility

Designed as an OEM-style compact splicing connector suitable for general electrical splicing in residential and light commercial wiring systems.

Installation Notes

Installation should be performed by a licensed electrician or qualified technician in accordance with applicable NEC requirements. Always de-energize the circuit at the breaker and verify zero voltage with a meter before making or disturbing any splice. Strip conductors to exactly 0.375 inches to ensure full seating and a secure connection. Do not exceed the connector's rated voltage or amperage for the conductor size being used.

Technical Specifications

• Voltage Rating: 250 volts
• Amperage Rating: 32 amps
• Wire Range (Solid): 28-12 AWG
• Wire Range (Stranded): 28-14 AWG
• Strip Length: 0.375 inches
• Material: Flame-retardant nylon PA66
• Package Weight: 0.25 pounds each
• Standard Carton Quantity: 24 pieces

Standard Information

• Brand: ZEBRA
• Manufacturer Part Number: zslck
