Product Description
The York S1-ZR32K5E-PFV-800 is a reliable scroll compressor designed for air conditioning systems. It offers a BTU rating of 32600 and operates at 208/230 VAC. This compressor is compatible with refrigerants R-22, R-407C, and R-134A.
- Designed for low-pressure applications
- Includes integrated internal protection
- Capacitor run with permanent split capacitor
Product Highlights
This compressor is built on over 30 years of scroll technology development, with proven performance in HVAC applications.
Product Information
Standard Information
-
Brand: York
-
Part Number: S1-ZR32K5E-PFV-800
Technical Specifications
-
Amperage Rating: 87 A Locked Rotor
-
BTU Rating: 32600 Btu/hr
-
Connection Type: 1/2 in Discharge x 3/4 in Suction
-
Dimension: 15.9 in H
-
EER: Up to 10.5
-
Foot Mount Size: 7-1/2 in
-
Frequency Rating: 60 Hz
-
HP Rating: 1 - 5 hp
-
Mass Flow: 456 lb/hr
-
Oil Type: 3MA Polyol Ester (POE)
-
Phase: 1 ph
-
RPM: 3500 rpm
-
Refrigerant: R-22/R-407C/R-134A
-
Tonnage: 2-1/2 ton
-
Voltage Rating: 208/230 VAC
