York S1-01505064004 Scroll Compressor 71.74 kBtu/hr 200/220 VAC at 50 Hz 208/230 VAC at 60 Hz R-407C

Product Description

The York S1-01505064004 is a scroll compressor designed for residential and light commercial air conditioning applications. This model features a BTU rating of seventy-one point seventy-four kBtu per hour and operates on both two hundred twenty VAC at fifty hertz and two hundred eight VAC at sixty hertz using refrigerant R-407C.

• Quick and easy installation
• Internal motor protection for enhanced durability
• UL listed and CE certified for safety

Product Highlights

The York S1-01505064004 is an efficient solution for air conditioning needs, capable of replacing various other compressors with similar connection patterns.

Product Information

Standard Information

• Brand: York
• Part Number: S1-01505064004

Technical Specifications

• BTU Rating: seventy-one point seventy-four kBtu/hour
• Color: Black
• Connection Type: Brazed, one half inch discharge x seven eighths inch suction
• Frequency Rating: fifty/sixty hertz
• Item Name: Scroll Compressor
• Oil Type: PVE
• Phase: three phase
• Pressure Rating: twenty-six point two to thirty-one point one bar
• RPM: two thousand nine hundred at fifty hertz, three thousand five hundred at sixty hertz
• Refrigerant: R-407C
• Temperature Rating: forty-five to one hundred thirty degrees Fahrenheit
• Tonnage: six tons
• Viscosity: sixty-eight cPs
• Voltage Rating: two hundred/220 VAC at fifty hertz, two hundred eight/230 VAC at sixty hertz
• Wattage: twenty-one kW
