York S1-01504475005 Scroll Compressor 54000 Btu/hr 208/230 VAC R-22/R-407C/R-134A

Product Description

The York S1-01504475005 is a scroll compressor designed for efficient cooling in air conditioning systems and various HVAC applications. With a BTU rating of fifty-four thousand, it operates at two hundred eight to two hundred thirty VAC, making it suitable for both residential and commercial settings.

• Capable of handling low-pressure applications.
• Uses R-22, R-407C, or R-134A refrigerants.
• Includes internal protection and a permanent split capacitor.

Product Highlights

This compressor is built on over thirty years of scroll technology development, ensuring reliability and efficiency in performance.

Product Information

Standard Information

• Brand: York
• Part Number: S1-01504475005

Technical Specifications

• Amperage Rating: 28.2 A Rated Load, 146 A Locked Rotor
• BTU Rating: 54000 Btu/hr
• Connection Type: 1/2 in Discharge x 7/8 in Suction
• Dimension: 16.9 in H
• EER: Up to 10.3
• Foot Mount Size: 7-1/2 in
• Frequency Rating: 60 Hz
• HP Rating: 1 - 5 hp
• Item Name: Scroll Compressor
• Mass Flow: 729/855 lb/hr
• Oil Type: 3MA Polyol Ester (POE)
• Phase: 1 ph
• RPM: 3500 rpm
• Refrigerant: R-22/R-407C/R-134A
• Tonnage: 4-1/2 ton
• Voltage Rating: 208/230 VAC
