York S1-01504225004 Scroll Compressor 49000 Btu/hr (4 Ton)

Product Description

The York S1-01504225004 is a scroll compressor rated 49,000 Btu/hr (4 ton) designed for R-410A air conditioners and configured for 208/230 VAC single-phase operation. It uses a capacitor-run (permanent split capacitor) design with internal inherent protection and a molded plug service connection. Performance specifications include 27.9 A rated load, 134 A locked rotor, 3,500 rpm, and an EER of 11+.

• Rated capacity 49,000 Btu/hr (4 ton) for R-410A air conditioning applications
• Electrical: 208/230 VAC, single-phase, 60 Hz; 27.9 A rated load, 134 A locked rotor
• Mechanical: scroll compressor, 1/2 in discharge x 7/8 in suction connections; 16.9 in height; 7-1/2 in foot mount

Product Highlights

Scroll compressor for 208/230 VAC single-phase R-410A systems, 49,000 Btu/hr capacity, capacitor-run with internal protection.

Product Information

Standard Information

• Brand: YORK
• Manufacturer Part Number: S1-01504225004

Technical Specifications

• Brand: York
• MPN: S1-01504225004
• Item Name: Scroll Compressor
• Capacity: 49,000 Btu/hr
• Tonnage: 4 ton
• Input Voltage: 208/230 VAC
• Phase: Single-phase
• Frequency: 60 Hz
• Rated Load Current: 27.9 A
• Locked Rotor Current: 134 A
• RPM: 3500 rpm
• EER: 11+
• Compressor Type: Scroll
• Run Type: Capacitor-run (permanent split capacitor)
• Refrigerant: R-410A
• Discharge Connection: 1/2 in
• Suction Connection: 7/8 in
• Height: 16.9 in
• Foot Mount Size: 7-1/2 in
• Oil Type: 3MA Polyol Ester (POE)
• Applications: Air conditioners
