York S1-01504142004 Scroll Compressor 24000 Btu/hr 208/230 VAC R-410A

Product Description

The York S1-01504142004 is a scroll compressor designed for air conditioning applications. It has a cooling capacity of twenty-four thousand BTU per hour and operates at voltage ratings of two hundred eight to two hundred thirty VAC. This compressor uses R-410A refrigerant.

• High temperature and ultra high pressure tolerance
• Capacitor run with permanent split capacitor
• Integrated internal protection for reliable performance

Product Highlights

The York S1-01504142004 includes significant innovations from over thirty years of scroll technology development. The fifth-generation fixed-speed design enhances efficiency and performance.

Product Information

Standard Information

• Brand: York
• Manufacturer: York

Technical Specifications

• Amperage Rating: 14.3 A Rated Load, 64 A Locked Rotor
• BTU Rating: 24000 Btu/hr
• Connection Type: 1/2 in Discharge x 3/4 in Suction
• Dimension: 15.3 in H
• EER: Up to 10
• Foot Mount Size: 7-1/2 in
• Frequency Rating: 60 Hz
• HP Rating: 1 - 5 hp
• Item Name: Scroll Compressor
• Mass Flow: 403/353 lb/hr
• Oil Type: 3MA Polyol Ester (POE)
• Phase: 1 ph
• RPM: 3500 rpm
• Refrigerant: R-410A
• Tonnage: 2 ton
• Voltage Rating: 208/230 VAC
