York S1-01504140004 Scroll Compressor 16000 Btu/hr 1-1/2 ton 208/230 VAC R-410A

Product Description

The York S1-01504140004 Scroll Compressor is used in air conditioning systems. This model has a cooling capacity of 16000 Btu/hr and operates on 208/230 VAC using R-410A refrigerant. It is a 5th generation fixed-speed compressor known for its reliability and efficiency.

• 16000 Btu/hr cooling capacity
• 208/230 VAC operating voltage
• R-410A refrigerant

Product Highlights

This 5th generation fixed-speed scroll compressor is suitable for air conditioners. It features high temperature and high-pressure capabilities, a capacitor run with permanent split capacitor, and internal inherent protection with a molded plug service.

Product Information

Standard Information

• Brand: York
• Manufacturer: York
• MPN: S1-01504140004

Technical Specifications

• Amperage Rating: 10 A Rated Load, 48 A Locked Rotor
• BTU Rating: 16000 Btu/hr
• Connection Type: 1/2 in Discharge x 3/4 in Suction
• Dimension: 14.3 in H
• EER: Up to 9.3
• Foot Mount Size: 7-1/2 in
• Frequency Rating: 60 Hz
• HP Rating: 1 - 5 hp
• Item Name: Scroll Compressor
• Mass Flow: 228/264 lb/hr
• Oil Type: 3MA Polyol Ester (POE)
• Phase: 1 ph
• RPM: 3500 rpm
• Refrigerant: R-410A
• Tonnage: 1-1/2 ton
• Voltage Rating: 208/230 VAC
