York JMET08BS2N1 Modular Multi-Position Air Handler 800 cfm

Product Description

The York JMET08BS2N1 is a modular multi-position air handler designed to provide reliable air flow at 800 cubic feet per minute (cfm). It has a compact design with dimensions of seventeen and a half inches high, twenty-three and three-fourths inches wide, and twenty-one and a half inches deep. This air handler features a robust construction that allows for easy installation in tight spaces.

• High-efficiency blower design for improved air flow.
• MaxAlloy coils for corrosion resistance and durability.
• Easy installation with a maximum depth of twenty-one inches.

Product Highlights

The York JMET08BS2N1 air handler is suited for HVAC applications with a maximum airflow of 800 cfm. Its modular design allows for flexible positioning and installation.

Product Information

Standard Information

• Brand: York
• Part Number: JMET08BS2N1

Technical Specifications

• Amperage Rating: 2.6 A
• CFM Rating: 800 cfm
• Dimensions: 17-1/2 in x 23-3/4 in H x 21-1/2 in D
• Filter Size: 16 x 20 x 1 in
• Frequency Rating: 60 Hz
• HP Rating: 1/3 hp
• Phase: 1 ph
• Series: JMET
• Type: Modular
• Voltage Rating: 208/230 VAC
