YORK 027-03020-000 York APAF 20 Piezo Ring

Product Description

The York APAF 20 Piezo Ring, MPN 027-03020-000, is a piezo actuator crafted for generating controlled motion. This actuator is suitable for integration in various systems and excels in applications such as precision machinery, optics alignment, and microelectronics assembly.

• Outer diameter measures twenty millimeters, with an inner diameter of twelve millimeters and a thickness of two point five millimeters.
• Supports a voltage range of zero to one hundred fifty volts.
• Operates effectively within a temperature range of negative forty degrees Celsius to positive eighty degrees Celsius.

Product Highlights

This piezo actuator provides reliable positioning and effective vibration damping for sensitive applications.

Product Information

Standard Information

• MPN: 027-03020-000
• Brand: York

Technical Specifications

• Dimensions: 20mm outer diameter, 12mm inner diameter, 2.5mm thickness
• Voltage Range: 0-150V
• Displacement: Up to 10µm
• Force: Up to 100N
• Frequency Response: Up to 10kHz
• Operating Temperature: -40°C to +80°C
• Category: HVAC
• Subcategory: Fan/Ventilation
