Yellow Jacket 69096 Digital Pressure Temperature Chart

Product Description

The YELLOW JACKET 69096 is a digital pressure temperature chart designed as a quick-reference tool for HVAC/R technicians working with refrigerant systems. It provides pressure-to-temperature correlation data in a digital or printed chart format, allowing technicians to verify system pressures and saturation temperatures without relying on memory or manual lookup tables. This type of reference tool is a standard addition to any service technician's kit and supports accurate diagnosis of refrigerant system performance in the field.

The 69096 is suited for use in residential and light commercial HVAC/R service work. Technicians use pressure temperature charts during system commissioning, refrigerant charging, leak diagnosis, and general performance evaluation. The chart supports workflow on split systems, package units, and refrigeration equipment where refrigerant pressure and saturation temperature relationships are critical data points.

Key Features

• Digital pressure temperature chart format for fast field reference
• Color: Yellow, consistent with YELLOW JACKET brand tooling
• Supports refrigerant pressure-to-saturation temperature lookups
• Compact design suited for use in the field

Compatibility

Designed as a general-purpose reference tool for HVAC/R technicians servicing refrigerant-based systems. No specific system or equipment compatibility limitations apply to a pressure temperature reference chart.

Installation Notes

This is a reference tool and does not require installation. Technicians should ensure the refrigerant system is properly isolated and that manifold gauges are connected according to standard service procedures before using pressure temperature data for diagnosis. Always follow EPA Section 608 guidelines when working with refrigerants.

Technical Specifications

• Color: Yellow
• UPC: 686800690964

Standard Information

• Brand: YELLOW JACKET
• Manufacturer Part Number: 69096
