Yellow Jacket 46015 4-valve Brute Ii A2L Manifold

Product Description

The YELLOW JACKET 46015 is a 4-Valve BRUTE II A2L manifold designed for use with mildly flammable A2L refrigerants including R32, R454B, and R410A. Built around an aluminum alloy body with 3/8 inch bores throughout, it delivers a faster flow rate than conventional manifolds, reducing charge and recovery times on the job. The manifold ships with 3-1/8 inch gauges and 60 inch PLUS II ball valve charging hoses. The double O-ring piston design improves sealing reliability and extends service life compared to single-seal configurations. This tool is suited for HVAC technicians working on modern residential and light commercial systems that use lower-GWP A2L refrigerant blends.

The 46015 is intended for field use during installation, commissioning, and service of split systems, heat pumps, and other refrigeration circuits charged with R32, R454B, or R410A. The 4-valve configuration allows independent control of each circuit port, giving technicians precise management of suction, discharge, and utility connections during charging and evacuation procedures. The included 60 inch PLUS II ball valve hoses provide enough reach for most rooftop and air handler access scenarios without additional hose extensions.

Key Features

• A2L refrigerant compatible — rated for R32, R454B, and R410A
• Aluminum alloy body with 3/8 inch bores throughout for high flow rate
• 4-valve design allows independent control of each manifold port
• Double O-ring piston construction for improved seal reliability and longer service life
• Includes 3-1/8 inch gauges for clear pressure readings
• Ships with 60 inch PLUS II ball valve charging hoses

Compatibility

Designed for use with A2L refrigerants R32, R454B, and R410A. Suitable for residential and light commercial HVAC systems charged with these refrigerant types.

Installation Notes

Installation and service of A2L refrigerant systems must be performed by EPA Section 608 certified HVAC technicians following applicable safety codes and local regulations governing mildly flammable refrigerants. Always recover refrigerant before disconnecting hoses and ensure the work area is properly ventilated when handling A2L refrigerants. Inspect all hose connections and O-rings for wear before use. Do not use this manifold with refrigerants outside its stated compatibility range.

Technical Specifications

• Compatible Refrigerants: R32, R454B, R410A
• Refrigerant Safety Class: A2L
• Valve Configuration: 4-Valve
• Body Material: Aluminum Alloy
• Bore Size: 3/8 inch throughout
• Gauge Diameter: 3-1/8 inches
• Hose Length: 60 inches
• Hose Type: PLUS II Ball Valve Charging Hose

Standard Information

• Brand: YELLOW JACKET
• Manufacturer Part Number: 46015
