Yale AU4704LN-626 Entry Lever Lockset Grade 1 Satin Chrome

Product Description

The YALE AU4704LN-626 is a Grade 1 entry lever lockset designed for residential and light commercial doors ranging from 1-3/8 to 1-3/4 inches thick. It features a key-in-lever cylinder with a 2-3/4 inch backset and is constructed with an all-metal chassis for lasting durability. The satin chrome finish gives the unit a clean, professional look. This lockset is non-handed, meaning it installs on left- or right-swing doors without modification. Licensed locksmiths, door hardware installers, and general contractors are the typical trades that specify and install this hardware on entry door applications.

This lockset is suited for entrance door applications in residential buildings and light-to-medium-duty commercial settings. The key-in-lever design requires a key from the exterior while allowing free egress from the interior. The freewheeling trim feature reduces torque on the cylinder during forced-entry attempts. With ANSI/BHMA A156.2 Series 4000 Grade 1 certification and UL/cUL listing, this unit meets recognized code requirements for commercial-grade door hardware. It is part of the YALE 4700LN series.

Key Features

• Grade 1 security rating per ANSI/BHMA A156.2 Series 4000
• Key-in-lever cylinder compatible with Schlage keyways
• Non-handed design installs on left- or right-swing doors without adjustment
• Freewheeling trim reduces mechanical stress on the cylinder during forced-entry events
• All-metal chassis construction for strength and long service life
• UL/cUL listed for use in rated applications

Compatibility

Designed for doors 1-3/8 to 1-3/4 inches thick with a standard 2-3/4 inch backset. Part of the YALE 4700LN series. Cylinder type is key-in-lever, Schlage keyway.

Installation Notes

Installation is performed by a licensed locksmith or qualified door hardware installer. Power down any access control or electric strike circuits before working on the door assembly. Verify door thickness and backset measurement before ordering to confirm fit. Follow ANSI/BHMA and local building code requirements for hardware installation in commercial or multi-family residential applications.
