Yale AU4701LN-626 Passage Lever Lockset Satin Chrome

Product Description

The YALE AU4701LN-626 is a keyless passage lever lockset designed for interior doors where free passage is required without locking function. Built on an all-steel chassis with a satin chrome finish, this unit fits doors ranging from 1-3/8 to 1-3/4 inches thick with a 2-3/4 inch backset. It carries a Grade 1 ANSI/BHMA A156.2 Series 4000 rating, making it suitable for demanding commercial and institutional applications. The freewheeling trim and non-handed design simplify specification and installation across mixed door orientations. Licensed locksmiths, commercial door hardware installers, and facilities maintenance professionals are the typical end users.

This passage lever lockset is appropriate for interior corridors, office suites, storage rooms, and other commercial or institutional spaces where access control is not required at the door level. Its Grade 1 rating positions it for light-duty to medium-duty applications in both residential and commercial environments. The non-handed configuration means a single SKU covers both left-hand and right-hand swing doors, reducing inventory complexity on multi-door projects.

Key Features

• Keyless passage function — lever operates freely from both sides, no lock cylinder
• Non-handed and freewheeling trim — installs on left-hand or right-hand doors without modification
• All-steel chassis construction for durability in commercial environments
• Satin chrome finish (626) provides a clean, professional appearance
• ANSI/BHMA A156.2 Series 4000 Grade 1 certified for reliability under repeated use cycles
• UL and cUL listed — supports compliance documentation on commercial projects

Compatibility

Designed for doors ranging from 1-3/8 to 1-3/4 inches thick with a 2-3/4 inch backset. Part of the Yale 4700LN series.

Installation Notes

Installation should be performed by a licensed locksmith or qualified door hardware technician familiar with ANSI standard preparation. Verify the door prep matches the 2-3/4 inch backset and confirm the bore diameter meets the manufacturer specification before installation. No keying is required for this passage function unit. Follow local building codes and any applicable ADA hardware guidelines when selecting lever hardware for accessible routes.
