Bell & Gossett 115119 EC-3X Suction Diffuser Plus 4 inch Flg x 2-1/2 inch Flg

Product Description

The Bell & Gossett EC-3X Suction Diffuser Plus, model number 115119, is a high-performance device designed to optimize the flow and efficiency of HVAC systems. This suction diffuser features a robust cast iron construction, making it ideal for commercial and industrial applications.

• Enhances system performance by conditioning the flow into the pump, ensuring maximum efficiency.
• Compact design combines functionality of an elbow and strainer, saving space and reducing installation costs.
• Equipped with an EPDM o-ring and a 16 mesh bronze strainer for reliable operation.

Product Highlights

This suction diffuser stabilizes the hydraulic conditions in the piping system, leading to reduced pressure drops and improved pump performance. Its design allows for quick and straightforward installation and maintenance.

Technical Specifications

• Connection size: 4 inch flanged (system side) x 2-1/2 inch flanged (pump side)
• Maximum operating pressure: 175 psi
• Maximum operating temperature: 250 degrees Fahrenheit
• Body material: Cast iron
• Strainer type: 16 mesh bronze
