Xtrweld WTPURE093 Pure Tungsten Electrode, 3/32, 10 Piece, 7 Inch L

Product Description

The XTRWELD WTPURE093 pure tungsten electrode is used for gas tungsten arc welding (GTAW). The GTAW process relies on tungsten's hardness and high-temperature resistance to carry the welding current to the arc. These ground electrodes are 3/32 in. (2.4mm) x 7" in length and meet AWS A5.12 EWP specifications.

• Used for manufacturing gas tungsten arc welding GTAW electrodes
• Relies on tungsten's hardness and high-temperature resistance to carry the welding current to the arc
• Tungsten has the highest melting point of any metal, 3,410 Degrees Celsius

Product Highlights

The XTRWELD pure tungsten electrodes are engineered for GTAW/TIG applications, offering superior arc stability and a clean, balled tip when heated, making them ideal for AC welding, especially on aluminum and magnesium.

Product Information

Standard Information

• Brand: XTRWELD
• Manufacturer Part Number: WTPURE093
• Country of Origin: China

Technical Specifications

• MPN: WTPURE093
• ItemID: XTRWTPURE093
• UPCCode: 840349202587
• Manufacturer: XTRweld
• Brand: XTRweld
• UOM: Pack
• ProductCategory: Welding & Gas Supplies
• ProductSegment: Arc Welding & Consumables
• ProductLine: Tungsten Electrodes
• Country: CN
• Length: 8.25
• Width: 2.25
• Height: 0.25
• Specification: AWS A5.12 EWP
• Electrode Type: Pure (Green)
• Diameter: 3/32 in. (2.4mm)
• Package: 10pc. Pack
• Size: 3/32 in. 2.4mm
• Type: Ground
• Material: Tungsten
• Standards: EWP - ANSI/AWS A5.12, ISO6848
• Welding Method: TIG (GTAW)
• Melting Point: 3410°C
• AC Current Range (With Oxide): 120 to 210 A
• DC Current Range (+) Pure Tungsten: 15 to 30 A
• Material Application: Aluminum; Magnesium
• DC Current Range (-) With Oxide: 150 to 250 A
• DC Current Range (-) Pure Tungsten: 120 to 220 A
• Impurities Mass Percent: 0.5% Max
• DC Current Range (+) With Oxide: 15 to 30 A
• AC Current Range (Pure Tungsten): 80 to 140 A
