Xtrweld WTLAN20040 2.0% Lanthanated Tungsten Electrode 10 Pack

Product Description

The XTRWELD WTLAN20040 is a 2.0% lanthanated tungsten electrode for gas tungsten arc welding (GTAW), sold in a 10-piece pack. At 0.040 inches in diameter and color-coded blue, this electrode is designed for precision TIG welding on steel, stainless steel, and other common weld metals. Lanthanated tungsten offers excellent arc starting, low burnoff, strong arc stability, and reliable reignition. It shares conductivity characteristics with 2% thoriated tungsten, making it a viable non-radioactive alternative for many applications. Licensed welders and skilled fabricators in HVAC, plumbing, and industrial trades rely on this electrode for clean, consistent welds.

The WTLAN20040 is suited for both AC and DC (-) welding processes. When used on DC or AC square wave power sources, it maintains a sharp pointed tip, which is ideal for welding carbon steel and stainless steel. It can also be balled for use with AC sine wave machines. Compared to 1.5% lanthanated tungsten, the 2.0% formulation delivers superior arc starting and improved AC performance, and in many cases it can replace 2% thoriated tungsten without requiring significant changes to existing welding programs or machine settings.

Key Features

• 2.0% lanthanated tungsten composition, color-coded blue for easy identification
• 0.040 inch diameter with a pointed end suitable for DC and AC square wave welding
• Excellent arc starting and reignition characteristics on both AC and DC (-)
• Low burnoff rate extends electrode service life compared to pure tungsten
• Can replace 2% thoriated tungsten in many applications without major program changes
• Compatible with AC sine wave machines when balled tip configuration is used

Compatibility

Designed for use with GTAW (TIG) welding equipment operating on AC or DC (-) power, including square wave and sine wave power sources. Suitable for welding steel, stainless steel, and similar base metals.

Installation Notes

Installation and use of GTAW electrodes should be performed by qualified welders following applicable AWS standards and shop safety procedures. Always power down and de-energize the welding machine before inserting or changing the electrode in the torch collet. Ensure the collet body and collet are matched to the 0.040 inch electrode diameter before striking an arc. Proper ventilation is recommended when welding, as all welding processes generate fumes.

Technical Specifications

• Electrode Diameter: 0.040 inches
• Tungsten Type: 2.0% Lanthanated
• Color Code: Blue
• Process: GTAW (TIG), AC and DC (-)
• Pack Quantity: 10 pieces
• Package Weight: 0.13 pounds
• Package Length: 8.1 inches
• Package Width: 2 inches
• Package Height: 0.25 inches

Standard Information

• Brand: XTRWELD
• Manufacturer Part Number: WTLAN20040
