Woodford RB67C-14 Model RB67 14 inches 3/4 inches Copper Water Tube Inlet Freezeless Backflow Preventer Round Box Wall Hydrant

Product Description

The WOODFORD RB67C-14 Model RB67 is an automatic draining, freezeless wall hydrant with hose connection backflow protection. Hydrants drain as the handle is shut off, even if a hose is attached. Designed for irrigation purposes and to blend with modern architecture for installation on various buildings. It installs through a 6" diameter hole.

• Permanent type brass valve body with hemispherical seating surface.
• One piece valve plunger accurately controls both flow and drainage.
• Drains under nozzle away from hands of operator and with a lip to divert water away from building.

Product Highlights

The Woodford RB67C-14 is a freezeless wall hydrant with backflow protection, designed for irrigation and commercial applications. It features automatic draining and a durable brass valve body.

Product Information

Standard Information

• Brand: WOODFORD
• Manufacturer Part Number: RB67C-14
• Country of Origin: USA

Technical Specifications

• ASSE Standard: 1052 approved
• Field Testable: True
• Check Valves: Two Independent
• Spray Back: No
• Max Pressure: 125 p.s.i.
• Max Temperature: 120 °F
• Product Type: Wall Hydrant
• Finish: Chrome Plated
• Wall Thickness: 14"
• Overall Size: 18-3/8"
• Inlet Type: Sweat
• Max Operating Pressure: 125 psi
• Size: 3/4"
• Lead Free: No
• Anti-Siphon: No
• Application: Commercial
• Manufacturer: Woodford
• Part Number: RB67C-14
• Inlet Style: 3/4” Copper Water Tube
• Package Quantity: 1
• Height: 1.000 IN
• Length: 14 in.
• Width: 1.000 IN
• Model: RB67
• Maximum Working Temperature: 120
• Inlet Size: 3/4 In.
• Material: Brass
• Maximum Pressure Rating: 125
• TAA/BAA Compliant: Yes
