Wiring Device-Kellems RRD155GY 1-Phase Decorator Single Standard Self-Grounding Straight Blade Receptacle NEMA 6-15R

Product Description

The Wiring Device-Kellems RRD155GY is a reliable straight blade receptacle designed for residential use. This 1-phase decorator single standard self-grounding straight blade receptacle operates at a voltage of 250 VAC and features a current rating of 15 A. It integrates 2 poles, 3 wires, and includes a NEMA 6-15R rating suitable for various applications.

• Self-grounding feature enhances safety.
• Constructed from durable thermoplastic material.
• Designed for easy installation with side wire terminals.

Product Highlights

The RRD155GY is a versatile and efficient choice for homes looking to maintain reliable electrical connections. Its gray color and compact dimensions fit well in multiple settings.

Product Information

Standard Information

• Brand: Wiring Device-Kellems
• Part Number: RRD155GY HW

Technical Specifications

• Voltage Rating: 250 VAC
• Amperage Rating: 15 A
• Horsepower: 1-1/2 hp
• Number of Poles: 2
• Number of Wires: 3
• Dimensions: 1.29 in W x 1.01 in D x 4.2 in H
• Material: Thermoplastic
• Enclosure: NEMA 6-15R
• Grade: Residential
• Terminal Type: Side Wire
