Wiring Device-Kellems RR430 Power Receptacle 1-Phase Dryer Range Surface Mount 125/250 VAC

Product Description

The Wiring Device-Kellems RR430 is a power receptacle designed for 1-phase dryer range applications. It operates at 125/250 VAC, with a current rating of thirty amperes. This surface mount device features three poles and four wires, making it suitable for various residential electrical setups.

• Voltage Rating: 125/250 VAC
• Amperage Rating: 30 A
• NEMA Rating: 14-30R

Product Highlights

This receptacle supports easy wire termination and complies with electrical safety standards. It features a pressure screw terminal system for secure connections, making it ideal for both new installations and replacements in residential settings.

Product Information

Standard Information

• Brand: Wiring Device-Kellems
• Manufacturer: Hubbell

Technical Specifications

• Type: 1-Phase Dryer Range Surface Mount
• Material: Thermoplastic/Composite
• Color: Black
• Temperature Rating: 75 deg C
• Dimensions: 2.5 in W x 2.21 in D x 5.49 in H
• Terminal Type: Pressure Screw
• Number of Poles: 3
• Number of Wires: 4
