Wiring Device-Kellems RCD111W 2-Position Standard Combination Switch 120/277 VAC

Product Description

The Wiring Device-Kellems RCD111W is a 2-position standard combination switch suitable for various applications. It operates at a voltage of 120/277 VAC and provides a power rating of 4155 W. This combination switch features a snap switch action and is designed with a rocker actuator. It ensures easy installation with threaded mounting and side wire terminals.

• Designed for 120/277 VAC voltage
• Operating cycles of up to 30000
• Environmental rating of -20 to 60 degrees Celsius

Product Highlights

This combination switch integrates practical functionality with user-friendly design. Ideal for both residential and commercial settings, it allows for diverse applications while maintaining high performance.

Product Information

Standard Information

• Brand: Wiring Device-Kellems
• Manufacturer: Hubbell

Technical Specifications

• Action: Snap Switch
• Actuator: Rocker
• Color: White
• Dimensions: 1.32 inches W x 1 inch D x 4.2 inches H
• Environmental Conditions: -20 to 60 degrees Celsius Operating Temperature
• Mounting: Threaded
• Number of Poles: 1
• Operating Cycles: 30000 Cycles
• Series: Decorator
• Terminal Type: Side Wire
• Type: 3-Way 2-Position Standard
• Voltage Rating: 120/277 VAC
• Amperage Rating: 15 A
• Power Rating: 4155 W
• Contact Configuration: 2-Position
