Wiring Device-Kellems L720P Twist-Lock Locking Male Plug 20 A 277 VAC

Product Description

The Wiring Device-Kellems L720P is a twist-lock locking male plug designed for safe electrical connections. This plug has a NEMA L7-20P rating suitable for commercial and industrial applications. It provides a disconnect solution between an equipment load and a power source. The locking interface is easily engaged or disengaged by rotating the device.

• Locking design for safe connections
• Rated for 277 VAC and 20 A
• Compatible with NEMA L7-20P standards

Product Highlights

The L720P is ideal for equipment where safety and reliability are crucial. It performs well across various environments, ensuring effective functionality in demanding situations.

Product Information

Standard Information

• Manufacturer: Hubbell
• Brand: Wiring Device-Kellems

Technical Specifications

• Type: Locking Plug
• Amperage Rating: 20 A
• Voltage Rating: 277 V
• Number of Poles: 2
• NEMA Rating: NEMA L7-20P
• Number of Wires: 3
• Temperature Rating: -40 to 60 deg C
• Terminal Type: Pressure Screw
