Wiring Device-Kellems L520C HWD Twist-Lock Connector Body 125 VAC 20A L5-15R

Product Description

The Wiring Device-Kellems L520C is a twist-lock connector body designed for safe and reliable electrical connections. This locking device operates at 125 VAC and is rated for 20 amps with two poles and three wires. The connector features a black and white composite body for durability.

• Easy installation with screw terminals
• Color-coded for NEMA rating identification
• Designed for heavy-duty industrial applications

Product Highlights

The L520C twist-lock connector offers a secure connection that can be easily engaged and disengaged by rotating the device. It is suited for a variety of commercial and industrial applications.

Product Information

Standard Information

• Brand: Wiring Device-Kellems
• Manufacturer: Hubbell Wiring Device-Kellems

Technical Specifications

• Voltage Rating: 125 VAC
• Amperage Rating: 20 A
• Number of Poles: 2
• Number of Wires: 3
• Temperature Rating: -40 to 75 degrees C
• NEMA Rating: L5-15R
• Cord Diameter: 0.385 to 1.15 inches
• Material: Composite
