Wiring Device-Kellems HBLDS3AC 2-Position Non-Fusible Standard Enclosed Disconnect Switch

Product Description

The Wiring Device-Kellems HBLDS3AC is a circuit-lock enclosed disconnect switch designed for non-fusible applications. This model features a 2-position contact system, operates at a voltage of six hundred volts, and has an amperage rating of thirty amps. It supports a horsepower of fifteen and is suitable for three-phase usage.

• Non-fusible disconnect switch for safety
• Durable NEMA 4X enclosure
• Lever actuator for easy operation

Product Highlights

This disconnect switch is built for reliability and safety, making it ideal for various industrial applications.

Product Information

Standard Information

• Manufacturer: Hubbell
• Brand: Wiring Device-Kellems

Technical Specifications

• Actuator Type: Lever
• Color: Gray
• Dimensions: Eight point five x Six x Four point twelve inches
• Enclosure Type: NEMA 4X
• Frequency Rating: Sixty Hz
• Material: Composite
• Mounting Type: Foot
• Number of Wires: Three
• Phase: Three
• Temperature Rating: Minus forty to seventy-five degrees Celsius
• Terminal Type: Screw
• Type: 2-Position Non-Fusible Standard
• Voltage Rating: Six hundred volts
• Amperage Rating: Thirty amps
• Horsepower: Fifteen hp
• Contact Form: 2-Position
• Number of Poles: Three
