Wiring Device-Kellems HBL5366CA 1-Phase Grounding Portable Standard Cord Mount 125 VAC 5-20P

Product Description

The Wiring Device-Kellems HBL5366CA is a durable and efficient cord mount straight blade plug. It operates at one hundred twenty-five volts AC, with a twenty amp capacity, and features two poles and three wires for versatile applications.

• Designed for commercial and industrial use
• Built to withstand environmental challenges with IP20 enclosure
• Includes Insulgrip technology for enhanced safety

Product Highlights

This straight blade plug is engineered with advanced insulation and durability. The Insulgrip design ensures a strong grip on cords while providing maximum safety for users.

Product Information

Standard Information

• Brand: Wiring Device-Kellems
• Manufacturer: Hubbell

Technical Specifications

• Voltage Rating: 125 VAC
• Amperage Rating: 20 A
• Cord Diameter: 0.325 to 0.655 in
• Dimensions: 1.21 x 1.52 x 2.08 in
• Enclosure: IP20
• Grade: Commercial/Industrial
• Horsepower: 1 hp
• Material: Polycarbonate
• NEMA Rating: 5-20P
• Temperature Rating: -40 to 75 deg C
• Terminal Type: Screw
• Number of Poles: 2
• Number of Wires: 3
• Color: Black/White
