Wiring Device-Kellems HBL5278C Twist-Lock Insulgrip 1-Phase Male Grounding Straight Blade Screw Mount

Product Description

The Wiring Device-Kellems HBL5278C is a reliable Twist-Lock Insulgrip device designed for the entertainment industry. It ensures secure connections under demanding conditions. This model is suitable for applications requiring a one-phase male grounding straight blade screw mount. It operates at a voltage of one hundred twenty-five volts and an amperage of fifteen amperes.

• Impact resistant nylon construction
• Temperature rated from negative forty to seventy-five degrees Celsius
• Includes a sturdy mounting screw for easy installation

Product Highlights

The sturdy construction of the HBL5278C makes it ideal for industrial settings. Its twist-lock feature ensures safety and stability during use.

Product Information

Standard Information

• Brand: Wiring Device-Kellems
• MPN: HBL5278C

Technical Specifications

• Dimensions: 1.71 x 1.69 x 1.71 in
• Grade: Heavy Duty/Specification
• Horsepower: 1/2 hp
• Material: Nylon
• NEMA Rating: 5-15P
• Temperature Rating: -40 to 75 deg C
• Terminal Type: Screw
• Voltage Rating: 125 VAC
• Amperage Rating: 15 A
• Number of Poles: 2
• Number of Wires: 3
• Color: White
