Wiring Device-Kellems HBL4779C Grounding Heavy Duty Straight Blade Cord Mount 277 VAC L7-15R

Product Description

The Wiring Device-Kellems HBL4779C is a heavy-duty grounding straight blade cord mount locking connector suitable for various commercial and industrial applications. This product operates at a voltage rating of two hundred seventy-seven volts alternating current (VAC) and supports a maximum amperage of fifteen amps. The device features two poles and three wires, ensuring reliability in electrical connections.

• Grounding heavy-duty straight blade cord mount
• Commercial and industrial grade with high impact resistance
• Temperature rating from negative forty to seventy-five degrees Celsius

Product Highlights

The HBL4779C is designed with a ribbed nylon housing that provides a secure grip while being impact and chemical resistant. It features a superior cord grip design to protect terminations from stress. The integral VARI-SIZE insert allows accommodation for a wide range of cord diameters.

Product Information

Standard Information

• Manufacturer: Hubbell
• Series: HBL®

Technical Specifications

• Voltage Rating: 277 VAC
• Amperage Rating: 15 A
• Horsepower: 2 hp
• Color: Black/White
• Material: Nylon
• Number of Poles: 2
• Number of Wires: 3
• Cord Diameter: 0.23 to 0.72 in
• Dimensions: 1.53 x 1.53 x 2.78 in
• Enclosure: IP20
• NEMA Rating: L7-15R
• Temperature Rating: -40 to 75 deg C
• Terminal Type: Pressure Screw
