Wiring Device-Kellems CR20LATR 1-Phase Duplex Self-Grounding Standard Tamper Resistant Traditional Screw Mount 125 VAC

Product Description

The Wiring Device-Kellems CR20LATR is a 1-Phase Duplex Self-Grounding Receptacle. It features tamper-resistant protection and a traditional screw mount design. This receptacle operates at 125 VAC with a maximum current of 20 A, making it suitable for a variety of electrical applications.

• 1-Phase duplex design
• Commercial grade with 5-20R NEMA rating
• Temperature rated from -40 to 75 degrees Celsius

Product Highlights

This straight blade receptacle provides reliable performance in both residential and commercial settings.

Product Information

Standard Information

• Brand: Wiring Device-Kellems
• Manufacturer: Hubbell

Technical Specifications

• Voltage Rating: 125 VAC
• Amperage Rating: 20 A
• Horsepower: 1 hp
• Number of Poles: 2
• Number of Wires: 3
• Color: Light Almond
• Material: Nylon
• Dimensions: 1.32 x 1.14 x 3.28 in
• NEMA Rating: 5-20R
• Terminal Type: Side Wired
